PCS
Energy Storage Converter 15kW | 25kW | 30kW | 40kW | 50kW | 60kW
HBPS energy storage inverter series 15~60kW, 3 phase, HV battery 200-850V, efficiency >97%, support parallel, fast on/off grid switching. Suitable for villas, factories, small islands. Warranty: 5 years.
Reference price: $3,309.00
Stock: confirmed by orderFor households, installers, dealers, hotels, villas, and factories.
Battery, inverter, PV panel, and accessory availability is confirmed within 24h by city, quantity, and project configuration.
Warranty 5 years
Worldwide shipping
100% Original
Main Features
- Conversion efficiency >97%
- High voltage HV battery 200-850V, compatible with 280/314Ah cells
- 3 phase 400V, support parallel multiple units
- Fast on/off grid switching <15ms
- Support run with diesel generator
- Suitable for villa, factory, small island, farm
Technical Specifications
| 15kW | 25kW | 30kW | 40kW | 50kW | 60kW | |
|---|---|---|---|---|---|---|
| Power | 15kW / 15kVA | 25kW / 25kVA | 30kW / 30kVA | 40kW / 40kVA | 50kW / 50kVA | 60kW / 60kVA |
| Max AC current | 22A | 36A | 43.5A | 57.7A | 72.1A | 87A |
| Max battery current | 85A | 80A | 100A | 120A | 150A | 180A |
| Off-grid power | 15kVA | 27.5kVA | 30kVA | 40kVA | 50kVA | 60kVA |
| Size | 540×430×170 mm | 540×430×170 mm | 540×430×170 mm | 600×600×900 mm | 600×600×900 mm | 600×600×900 mm |
| Weight | 35 kg | 38 kg | 40 kg | 90 kg | 95 kg | 100 kg |
| Warranty | 5 years | 5 years | 5 years | 5 years | 5 years | 5 years |
| MPPT | - | - | - | 2 channel, PV max 40kW | 2 channel, PV max 50kW | 2 channel, PV max 60kW |
| Type | Energy storage converter (PCS) | Energy storage converter (PCS) | Energy storage converter (PCS) | Energy storage converter (PCS) | Energy storage converter (PCS) | Energy storage converter (PCS) |
| Battery voltage | HV 200~850VDC | HV 200~850VDC | HV 200~850VDC | HV 200~850VDC | HV 200~850VDC | HV 200~850VDC |
| AC grid | 400V/230V 3 phase, 50/60Hz | 400V/230V 3 phase, 50/60Hz | 400V/230V 3 phase, 50/60Hz | 400V/230V 3 phase, 50/60Hz | 400V/230V 3 phase, 50/60Hz | 400V/230V 3 phase, 50/60Hz |
| Efficiency | >97% | >97% | >97% | >97% | >97% | >97% |
| On/off grid switching | <15ms | <15ms | <15ms | <15ms | <15ms | <15ms |
| Parallel | Support multi-unit parallel | Support multi-unit parallel | Support multi-unit parallel | Support multi-unit parallel | Support multi-unit parallel | Support multi-unit parallel |
| Communication | RS485, CAN | RS485, CAN | RS485, CAN | RS485, CAN | RS485, CAN | RS485, CAN |
| Temperature | -30~60°C | -30~60°C | -30~60°C | -30~60°C | -30~60°C | -30~60°C |
| Cooling | Forced fan cooling | Forced fan cooling | Forced fan cooling | Forced fan cooling | Forced fan cooling | Forced fan cooling |
Batteries Wey Fit
Questions Wey People Dey Ask
Wetin be di warranty for Energy Storage Converter 15kW | 25kW | 30kW | 40kW | 50kW | 60kW?▼
Energy Storage Converter 15kW | 25kW | 30kW | 40kW | 50kW | 60kW get 5 years warranty from Batelithium. We go give you full technical support for di warranty time.
Una dey ship to oda countries?▼
Batelithium dey ship go anywhere for world. Free shipping for bulk orders. Contact our team make we give you custom quote.
